SPICE models for Johanson Dielectric’s X2Y series of components are available for download. This contains specific SPICE models for both components when used in EMI Filtering or Power Bypass applications and two illustrative explanations. SPICE models allow circuit designers to run circuit simulations prior to the actual production of hardware, which is a frequent request…
Johanson has extended the product family of 5G Cellular Band Pass Filters with the addition of n77 and n79. These new series of low profile (0.35mm max.) high attenuation Band Pass Filters are specially designed for modules and platforms where thickness or height comes at a premium. These EIA 0603 (Metric 1608) SMD components offer…
Check out the article in “Microwaves & RF” regarding how Johanson’s advanced EMI Filters can help cut the costs on brush DC motors. Microwaves & RF provides information and resources for its audience of a specialist in high-frequency electronic design. Read the article
The need for signal reception of more than one satellite system has become standard practice. As a response to this, Johanson Technology has developed a surface mount (SMT) Antenna that operates from 1560 to 1605MHz. This means, our newest Chip Antenna, p/n 1582AT54A0045 can function at GPS, GLONASS (GNSS), BeiDou (BDS), and Galileo. New navigation…
